Product NumberRR-2V2L-18PA-R1
CPU SocketIntel® LGA 1700 / 1200 / 1151 / 1150 / 1155 / 1156 socket
CPU SocketAMD® AM5 / AM4 socket
Dimensions (L x W x H)120 x 80.5 x 157 mm / 4.7 x 3.2 x 6.2 inch
Heat Sink Material4 Heat Pipes / Direct Contact / Aluminum Fins
Dimensions (L x W x H)120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch
Fan ProfilesAddressable RGB
Fan Speed650-1800 RPM ± 5%
Fan Air Pressure2.5 mmH2O (Max)
Fan Noise Level27 dBA (Max)
Fan Bearing TypeRifle Bearing
Fan Power Connector4-Pin (PWM)
Fan Power Consumption1.8W
NoteAM5 and LGA 1700 mounting kits are included from New Package Design. You may obtain the required mounting kits for products with older package design through the CM store, regional resellers or distributors. Older CPU sockets (LGA 2066, LGA2011-v3, LGA2011, LGA1366, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1) will not be supported anymore from New Package Design.
