Fan Power Connector4-Pin (PWM)
Fan Bearing TypeRifle Bearing
Fan Dimensions (L x W x H)92 x 92 x 25 mm / 3.6 x 3.6 x 1 inch
Fan Speed800-2200 RPM (PWM) ± 10%
Heat Sink Material2 Heat Pipes
Heat Sink MaterialAluminum Fins
Heat Sink MaterialDirect Contact
Fan Power Consumption2.4W
NoteAM5 and LGA 1700 mounting kits are included from New Package Design. You may obtain the required mounting kits for products with older package design through the CM store, regional resellers or distributors. Older CPU sockets (LGA 2066, LGA2011-v3, LGA2011, LGA1366, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1) will not be supported anymore from New Package Design.
Fan Air Pressure1.2 mmH2O
Dimensions (L x W x H)102 x 84.5 x 136 mm / 4.0 x 3.3 x 5.3 inch
Fan Airflow43.25 CFM (Max)
Product NumberRR-T200-22PK-R1
